10A 12V 24V 220VAC Digital LED Temperature Controller for Incubator Cooling Heating Switch Thermostat Ntc Sensor

How to set the controller:

1. Set the start temperature:

Press Up button show the starting temperature;

long press UP button the temperature display Flashing , press the UP or Down button to set the start temperature value.

2. Set the stop temperature:

Press Down button show the Stop temperature;

long press Down button the temperature display Flashing , press the UP or Down button to set the stop temperature value.

3. Restore factory settings:

Long press the  Up and Down bottons when the controller is powered, the display shows "888"  and switch to detection temperature.

Specifications:

Product name: microcomputer temperature controller

Model: XH-W3001

Input power: AC 110V 220V   DC 12V  DC 24V (Optional)

Temperature measurement range: - 50 ~ 110°C

Temperature control range: - 50 ~ 110°C

Temperature measuring accuracy: +/-0.2 °C

Temperature control precision: +/- 0.1 °C

Measuring input: NTC10K, 1 meters long waterproof probe

Output Type: Direct Output

Output Capacity: MAX 10A AC 220V  or  DC 12v 24v

Appearance size: 60 * 45 * 31 mm

Photos:
